Description
Monitor Mounting Plate CNC files
Mounting monitors, so they can be adjusted with the correct viewing angle can be tricky. so I have created a set of adjustment plates & vesa mounting plate so this task becomes simple.
Most towns have a wood CNC or water jet or laser cutting service, so it’s simple & cost-effective to have plates cut professionally locally saving on shipping costs.
What is included
- Full scale PDF files
- Two styles of monitor adjustment plate
- Vesa mount, 75*75, 100*100, 125*125 hole pattern
- T-Plate
- CNC files in DWG & DXF
- CAD file in step and iges format
Save money ordering aluminum extrusion
OSR recommends tnutz.com affiliate program they offer an excellent service, they ship world wide and you can use this link to to save over 35% compared to other suppliers.
Delivery
OSR will send you the digital plans normally within 24 hours. The digital plans are released using google drive, this process is 100% manual, so a little patience is sometimes required :-). It helps the process if you have a gmail account, but this is not essential.
Legal Stuff…
The plans are copyrighted and licensed for personal use only. The completed or partially completed sim rigs chassis is not permitted to be sold, resold, distributed, mass produced or used in any commercial fashion. The plans may not be reproduced or distributed in any manner.
